EW-120 fire curtain system

Fire curtain with low thermal emissivity MFB EW-120

Description

TECNITEX MFB EW-120 is a fire curtain with low thermal emissivity which, in case of fire, prevents the spread of flames, in addition to ignition of elements located at a safe distance by radiation.
Protective purpose
  • 120 minute fire resistance at over 1000ºC (Integrity).
  • Low emission of radiation for 60 minutes at 1000ºC ≤15 Kw/m2.
  • Large dimensions.
Characteristics

The system is made up of technical textile reference TECTEX 1120-IT/IN/L2, made from class E fibreglass reinforced with steel Inconel, covered with aluminium foil on both sides, acting as an element to limit thermal radiation.

Technical diagram

The MFB EW-120 fire curtain is installed with the purpose of integrity and reduced radiation. This system may replace systems with thermal isolation provided that a perimeter area is respected with regard to flammable elements or exhaust channels, without the need for irrigation systems. I'm interested
BOXMAXIMUM DIMENSIONSBOX DIMENSIONS (E/F) mm
WIDTH (A) mmHEIGHT (B) mm
SERIE-S2245003500220x220mm
SERIE-S2445007000240x260mm
BOXMAXIMUM DIMENSIONSBOX DIMENSIONS (E/F) mm
WIDTH (A) mmHEIGHT (B) mm
SERIE-R22120003500220x220mm
SERIE-R24120006500240x260mm
SERIE-R26120008000260x300mm
GUIDESMAXIMUM DIMENSIONSBOX DIMENSIONS (E/F) mm
WIDTH (A) mmHEIGHT (B) mm
SG-12012000Up to 450070x120mm
SG-13012000> 450070x130mm
